Product Description
|
Size |
Diameter (mm) |
Height (mm) |
Diamond Layer (mm) |
EX |
SH |
SM |
|
1004 |
10.40 |
4.50 |
1.8-2.2 |
• |
• |
• |
|
1204 |
12.30 |
4.50 |
1.8-2.2 |
• |
• |
• |
|
1304 |
13.33 |
4.50 |
1.8-2.2 |
• |
• |
• |
|
1305 |
13.33 |
5.00 |
1.8-2.2 |
• |
• |
• |
|
1308 |
13.40 |
8.00 |
1.8-2.2 |
• |
• |
• |
|
1313 |
13.40 |
13.20 |
2-2.2 |
• |
• |
• |
|
1613 |
16.05 |
13.2 |
2.2-2.8 |
• |
• |
• |
|
1913 |
19.05 |
13.2 |
2.2-2.8 |
• |
• |
• |
Product Overview
Excellent performance
1.High density (low porosity)
2.High uniformity of composition and structure
3.Excellent adhesion between diamond particles
4.High wear resistance
5.High impact resistance
6.High thermal stability
7.Optimized interface between diamond and tungsten carbide layer for excellent bonding
Diamond composite sheets are made by sintering diamond micropowders with a hard alloy matrix under ultra-high pressure and temperature. They possess the high hardness, wear resistance, thermal conductivity of diamond, as well as the strength and impact resistance of hard alloy. They are ideal materials for manufacturing cutting tools, drilling bits, and other wear-resistant tools. It has been widely used in industries such as oil drilling, geological exploration, coal mining drill bits, and mechanical processing tools.
FEATURES AT A GLANCE
Drilling and mining of PDC cutter
Suitable for drilling in soft and medium hard geological conditions with high impact toughness and thermal stability. High temperature resistance up to 750 ℃ (2 minutes), this product can be combined with flat and various groove shapes, and groove shapes can be designed, ground, products with special shapes, polished, chamfered, etc. according to user needs.
| PDC cutter for Coal mining,Geological exploration,Stone processing | |||
|
Model |
1005, 1304, 1308, 1313, 1608, 1613, 1908. 1913 |
1308 |
1305, 1308 |
|
Application |
Making geological and coalmine drill bits for medium-hard rocks |
Making geological&coalmine drill bits for soft rocks |
Makinggeological&coalmine drill bit for hard rocks |
|
Advantages |
High wear resistance and impact resistance. |
Faster rock breaking speed in soft rocks |
Longer useful life, and High impact resistance in hard rocks |
|
PDC cutters for oillgas drilling |
|
|
Model |
1005, 1308, 1313,1608,1613,1908, 1913, 1925 |
|
Application |
Mainly used for oil or gas drilling bits |
PRODUCT CONFIGURATION
Polycrystalline diamond composite sheets for coal field/mining drilling are designed and manufactured using advanced sintering techniques, selected high-quality diamonds and hard alloys sintered at high temperatures and pressures, specifically for coal field/mining drill bits. This product has the advantages of fast footage, high efficiency, less chip breakage, and economic practicality, and is designed and developed to meet the comprehensive needs of cost and efficiency. Widely used in geological exploration, coal field drilling and mining drill bits, and mechanical processing tools, mainly for the manufacturing and application of coal mines and mining drill bits.
Why did you choose us?
Zhengzhou Sungood New Material Technology Co., Ltd. has 15 years of professional experience in the production of mining machinery mining tools and accessories. Its main products include PDC cutting tools, PDC drill bits, diamond drill bits, etc. Our products are sold to multiple countries and regions, and we have established stable cooperative relationships with more than 20 customers worldwide.
What can we offer you？
Zhengzhou Sungood New Material Technology Co., Ltd. has been developing new products mainly based on diamond composite materials and efficiently producing the following drilling tools:
※ PDC cutting tools/blades: 1304, 1305, 1306, 1308, 1310, 1313, 1613, 1616, 1913... petroleum or mining types. ※ PDC core drill bits: diameter 46mm, 50mm, 55mm, 60mm, 65mm, 75mm, 89mm, 94mm, 98mm,113mm, 124mm, 127mm, 132mm, 146mm, 153mm, 190mm, 216mm，.......
※ PDC non core drill bits: including arc angle drill bits, flat top
drill bits, and concave drill bits, providing products of any size from 50mm to 300mm. According to your needs, you can produce products such as two wings, three wings, and four wings; PDC anchor rods for roof bolt support: diameter 25mm, 27mm, 28mm, 29mm, 30mm, 32mm, 35mm, 42mm, 43mm Hard alloy drill bits: double wing coal drill bits, chisel drill bits, cross drill bits, button drill bits, hammer heads According to your needs, we can provide you with customized products, including trademarks, packaging, etc
PACKAGING AND DELIVERY
Single carton box package, safe and regular placement.
Samples are shipped by express, batch products are shipped by sea or by air.
Delivery: 1-5 days for samples, 1-15 days for batch products.
