Product Classification
Factory 1308 Customized High-Grade Convex PDC Cutters Diamond Button / Inserts for Mining
Type: 1308 High-Grade Convex PDC Cutters Diamond layer thickness at center: 1.8-2.2 mm; Substrate: tungsten carbide with 6%-8% cobalt. Hardness: HRA >80. Thermal stability: up to 700degrees C.
Factory 1608 PDC Cutters Diamond Inserts / blades for Mining and Oil Field
Type: 1608 PDC Cutters The 1608 series serves both coal mining drag bits and oil field PDC bit construction, bridging two market segments that typically use different cutter specifications.
Factory 1613 High-Grade PDC Cutters Diamond Inserts Polycrystalline Diamond Compact
Type: 1613 High-Grade PDC Cutters Cutter diameter: 16.13mm. Table geometry: flat (convex available on request). Hardness: HRA >80 (highest in the SUNGOOD TECH cutter range). Thermal stability: up to 700 degrees C (standard), 750 degrees C (thermally stable grade).
Factory High-quality 1005 PDC Cutters Well Drill Bit Polycrystalline Diamond Compact for hard rock
Type: 1005 PDC Cutters Cutter diameter: 10.05mm. Table geometry: convex. Diamond layer thickness: 1.0-1.2mm. Substrate: tungsten carbide with 6%-8% cobalt.
Factory Standard 1304 PDC Cutters Polycrystalline Diamond Compact
Type: Standard 1304 PDC Cutters Cutter diameter: 13.04mm. Table geometry: flat. Diamond layer thickness: 1.0-1.2mm. Hardness: HRA >80.
Factory 1205 customized High wear resistance PDC Cutters
Type: 1205 customized PDC Cutters Cutter diameter: 12.05mm. Table geometry: convex. Diamond layer thickness: 1.0-1.2mm. Substrate: tungsten carbide with 6%-8%cobalt.
Factory 1005 Customized PDC Cutters Diamond Inserts Polycrystalline Diamond Compact
Type: 1005 customized PDC Cutters Cutter diameter: 10.05mm. Table geometry: flat (convex available on request). Diamond layer thickness: 1.0-1.1mm standard (1.2mm available).
